1.2 Functions of the operator panel
Name Function
(1) LED Lights when the scanner is turned ON.
(2) Function No. display Indicates the function No. and error status .
Buttons
(3) Function Changes the Function activated by the Send to button.
(4) Send to
Launches the linked application software.
(5) Scan
For the use of the Operator panel, open it as shown below.
• •
