8.6 Background Color Areas
Paper white detection is performed in the shaded area as shown in the Figure below. The top 3mm area on both sides of a document, should
have no printing.
When the [White Level Follower] is selected, the color of this area must be the dropout color (color you want to remove) or the document's
background color (white) .
If the above cannnot be performed, turn the [White Level Follower] off before scanning.
For the details on dropout color, please refer to section 3.5 Selecting a color to drop out .
