7.1 Online setup
"Software Operation Panel" is an application program that is installed with driver software (TWAIN/ISIS). This software allows you to
configure various settings for fi-5650C with user-friendly interfaces. To start this application, select [All Programs] - [Scanner Utility for
Microsoft Windows] from [Start] menu then click [FUJITSU Software Operation Panel]. Details of settings are as follows:
No Function Description Settings Default
1 Double feed
Specifies double feed
detection method. The
scanner monitors
differences in document
length, overlapping or
both, for detecting double-
feeds.
None / Check Overlapping / Check Length / Check overlapping
and length For setting the length difference detection, select 15 /
10 / 20mm
None
2 Page Edge Filler
Specifies area to be
erased from image
margins when scanning
documents.
Top/Bottom/Right/Left:
set the value from 0 to 15mm
(can be changed by 1mm)
(A: Image output area
B: Page Edge Filler area)
Top/Bottom/Right/
Left: 0mm
1 | 2
