5.1 Consumable and Replacement Cycle (Continued from the previous page)
The following message may appear while you use the scanner:
Replace consumables when this message is displayed.
After clicking the [Ignore] button, this message will disappear and scanning will continue. Please replace the consumable as soon as possible.
As a default, this message appears again after 1,000 scans. If you do not wish this message to display, click the [ this message not display
again].
To stop scanning and replace the consumable, click the [Cancel] button.
Replacement information is given in the following:
Brake Roller: see
5.2 Replacing the brake roller
Pick Roller: see 5.3 Replacing the pick roller set
