FUJITSU Image Scanner fi-5650C User Manual
Page 22

CONTENTS
1 NAMES AND FUNCTIONS OF PARTS
1.1 Names and functions of parts
1.2 Functions of the operator panel
3 SCANNING VARIOUS TYPES OF DOCUMENTS
8 DOCUMENT SPECIFICATION OF ADF
1.1 Names and functions of parts (Continued from the previous page)
No.
Name
No.
Name
17
Chute Roller
22
Plastic Roller
18
Pick Roller Set
23
Feed Roller
19
Sheet Guide
24
Ultra Sonic Sensor (Multi feed detection)
20
Brake Roller
25
Glass
21
Pick Arm
All Rights Reserved, Copyright (C) PFU LIMITED 2004
