6.2 Indications operator panel for errors (Continued from the previous page)
Indication
Meaning
EA
Imprinter malfunction (*)
Ec
Memory malfunction
Ed
Malfunction at SCSI interface controller
EF
Background switching mechanism malfunction
E10
ROM malfunction
E11
Fan malfunction
E12
Heater malfunction
E15
Extended memory board malfunction * See the ATTENTION below.
E16
Option board malfunction
E17
Imprinter fuse malfunction (*)
E18
Sensor malfunction
E19
LSI malfunction
E1A
Scanner inside communication malfunction
* "EA" and "A17" are alarms related with the Imprinter option (sold separately).
ATTENTION
An error has occurred to any of the additional memory boards installed by the user. Please check the following conditions given below, and
refer to "
will perform scanning operations with the extended memory boards deactivated.
1. Check for correct additional memory module number.
2. Is the additional memory board installed correctly?
3. Isn't the additional memory board broken?
4. Two memory boards are required, are there two installed?
When you encounter any alarm, turn off and on the scanner. If the alarm is still displayed on the Function No. display, turn off the scanner,
remove the additional memory board and check that the scanner functions correctly. Return the memory board where the memory was
purchased or contact an authorized FUJITSU scanner service provider.
