80
S t y l i s t i c L T 8 0 0 P T a b l e t
Checking the Connectivity 6
1. Click [Start] -> [Settings] -> [Control Panel].
2. Double-click the [PRISM Settings] icon. [PRISM Wireless Settings] appears.
3. Check the connectivity on the [Link] tab. The current condition of connection is
displayed.
Table A-7 Checking connectivity
Item Description
State
Shows the current condition of connection.
The MAC address of the other computer to which you are
connected is displayed when the connection is successful. If you are
connected to more than one computer, the computer that has the
best connectivity is displayed.
Current Channel Shows the current channel used for the connection.
Current Tx Rate Shows the current transfer rate in Mbits/sec.
[Radio Off]/
[Radio On] Click [Radio Off] to disconnect.
Click [Radio On] to connect to the network.
[Rescan] button Click this button to search for others to connect to.
Throughput
(Bytes/sec) Shows the actual transfer rate of the data transfer for send (Tx) and
receive (Rx).
Link Quality
Shows either [Excellent], [Good], [Fair], [Poor], or [Not Connected],
depending on the link quality.
Not shown for AdHoc connection.
Signal Strength
Shows either [Excellent], [Good], [Fair], [Poor], or [Not Connected],
depending on the signal strength.
Not shown for AdHoc connection.
