1-5
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Loading Documents
NOTE
Hold both ends and bend the
documents into an arch. Then hold
tightly and straighten them. The
center of documents swells and air is
introduced between the documents.
Line mark
Lock lever
Hopper guide
Extension
Adjust the hopper guides to the
document width. And load
documents face-up.
Load the document for reading.
Stacker
Lever
Hopper guide
Hopper table
Extension
15 to 20 mm
Fan the sheets before setting the
document on the hopper table.
NOTE
• Squeeze the lock lever to free the Hopper
guides.
• Remove paper clips and
staples. Flatten staple
holes with your finger.
• Load documents face-up.
• Stack must not exceed line mark.
• Use the extension for long documents.
• Do not mix different width documents.
