1-2
Units and Assemblies
This section shows the exterior view and assemblies of the scanner. This section also provides
names of each part and describes their functions.
■ Units
3 Hopper
1 Operator panel
2
Power switch
4 Hopper guide
5 Hopper extension
6 Automatic document feeder (ADF)
8
Pick roller unit
9 Guide plate
10
Pad
11
Brake roller
12
Upper transport unit
13 Side cover
14 Lever
16 Stacker guide
17
Stacker extension
19 Check stopper
18 Stop lever
15 Stacker
7 ADF release lever
23 Interface connectors 21 Power inlet
20 Main line switch
22 Interface connectors
