1. BASIC OPERATION
1-16
2. Select a menu item.
There are three ways to select a menu item. This manual uses method a).
a) Press the appropriate numeric key.
b) Rotate the [ENTER] knob to select the menu item desired, and then press the
[ENTER] knob.
The red cursor appears at left side of the item selected. Rotate the [ENTER]
knob clockwise to move the red cursor upward; counterclockwise for
downward.
c) Roll the trackball in up-down direction to select item, and then press the
[ENTER] knob.
For example, press the [8] key to display the PLOTTER SETUP menu.
8. PLOTTER SETUP
TURN KNOB TO SELECT MENU.
SELECT THE ITEM OF EACH MENU BY TRACKBALL.
LORAN-A GRI 00-01
CORRECTION 1 +000.0 µs
CORRECTION 2 +000.0 µs
LORAN-C GRI 00:11-29
CORRECTION 1 +000.0 µs
CORRECTION 2 +000.0
µs
DECCA CHAIN 01 R-G
CORRECTION 1 +00.00 LANE
CORRECTION 2 +00.00 LANE
TD DISPLAY 1. LORAN-A 2. LORAN-C 3. DECCA
RESET TRIP LOG 1. YES 2. NO
PLOTTER RANGE SETUP 1. YES 2. NO
PANEL-DIMMER 1 2 3 4 5 6 7 8
HUE 1. DAY 2. NIGHT 3. TWILI 4. MANUAL
00:1L0 01:1L1 02:1L4 03:1L5 04:1L6
05:1L7 06:1S1 07:1S2 08:1S3 09:1S4
10:1S6 11:2H3 12:2H4 13:2H5 14:2H6
15:2S0 16:2S1 17:2S2 18:2S3 19:2S4
20:2S5 21:2S6 22:2S7
Cursor (red rectangle)
Plotter setup menu
3. Rotate the [ENTER] knob to select item which you want to change the setting.
You can also select item by rolling the trackball in up-down direction.
4. Roll the trackball in left-right direction to select option (with the red rectangle).
When the option is a numeral, you can select it by pressing the appropriate
numeric key.
5. Press the [MENU] key several times to close the menu.
