Press the Enter button to clear the statistical data. Press the Exit button to abort
clearing the statistical data and to exit to the menu.
7.3.2
Select Fields
The SELECT FIELDS function allows you to select a display set (1 through 9)
to use for displaying information provided by the instrument. A display set can
be customized to display up to eight different fields. See the table of Field
Types below. When this function is selected, the bottom portion of the display
allows you to select the display set and also shows the information that is dis-
played for each set. To edit a display set, see Section 7.3.3, Edit Fields.
Use the
LR buttons to select the display set number. Press the Enter button
to save the new setting and exit. Press the Exit button to cancel and to exit to
the menu.
49
7 Menu Functions
Fields Menu
1
24.159C
3
24.142C
2
24.634C
4
24.015C
DISPLAY:
6
[2]*
SER
[3]*
-T1
[4]*
ALOG
[1]*
TYP
[6]*
STD
[7]*
SPR
[8]*
TIME
[5]*
AVE
EXIT
ENTER / MENU
UNIT
CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 21 Select Fields
