Installation Requirements
3-20 C156-E205-01EN
Eject pin (use a sealing tape)
Support (Front, Rear)
Eject pin (x 20)
Support (Middle)
Box
Shipping Label (2)
Master carton
(12/24 units)
Single-unit packing Multiple-unit packing
Conductive bag
MCJ3230AP
MCJ3230AP Desiccant
Desiccant
Figure 3.16 Packing style
(5) Transportation
a) Transport the optical disk drive packed in principle, with the UP sign upward.
b) After unpacking, minimize the transportation distance and use cushions to
avoid shock and vibration. Transport the drive in one of the orientations
described in Subsection 3.2.2 after unpacking. (The horizontal direction is
recommended.)
(6) Storage
a) Use moistureproof packaging when storing the drive.
b) The storage environment must satisfy the requirements specified in
Subsection 2.1.3 when the drive is not operating.
c) To prevent condensation, avoid sharp changes in temperature.
Conductive bag
