Contents
C156-E205-01EN
xiii
4.7.1 Register/PIO data transfer timing 4-78
4.7.2 Multiword DMA data transfer timing 4-80
4.7.3 Ultra DMA data in transfer (initialization timing) 4-82
4.7.4 Ultra DMA data in transfer (continuous transfer timing) 4-82
4.7.5 Ultra DMA data in transfer (host stop timing) 4-83
4.7.6 Ultra DMA data in transfer (device end timing) 4-83
4.7.7 Ultra DMA data in transfer (host end timing) 4-84
4.7.8 Ultra DMA data out transfer (initialization timing) 4-85
4.7.9 Ultra DMA data out transfer (continuous transfer timing) 4-85
4.7.10 Ultra DMA data out transfer (device stop timing) 4-86
4.7.11 Ultra DMA data out transfer (host suspend timing) 4-87
4.7.12 Ultra DMA data out transfer (device end timing) 4-88
4.7.13 Power-on and Reset Timing 4-90
CHAPTER 5 Operation and Cleaning ........................................................... 5-1
5.1 Operating Optical Disk Drive 5-1
5.1.1 Optical disk drive 5-2
5.1.2 Note 5-3
5.1.3 Inserting cartridge 5-3
5.1.4 Ejecting (removing) cartridge 5-5
5.2 Cleaning Drive 5-6
5.3 Optical Disk Cartridge Operation 5-7
5.3.1 Optical disk cartridge 5-7
5.3.2 Write protect tab 5-8
5.3.3 How to affix an index label on the MO cartridge (See figure 5.6) 5-9
5.3.4 Notes 5-9
5.4 Cleaning Optical Disk Cartridge 5-11
5.4.1 Cleaning tool 5-11
5.4.2 Cleaning procedure 5-12
CHAPTER 6 Diagnosis and Maintenance..................................................... 6-1
6.1 Diagnosis 6-1
6.1.1 Initial self-diagnosis 6-2
6.1.2 Diagnostic command 6-2
6.1.3 Test program 6-2
6.2 Maintenance Information 6-3
