Specifications

2-8

C156-E205-01EN

2.2.2 Optical disk cartridge

Figure 2.1 shows an optical disk cartridge. The figure below shows the cartridge
with its shutter open.

$

Shutter closed

$

Shutter open

Figure 2.1 Optical disk cartridge

3) Write protect tab

1) Cartridge case

2) Shutter

4) Disk

5) Hub
