• OnChip Primary/Secondary PCI IDE
The integrated peripheral controller contains an IDE inter face with suppor t for
two IDE channels. Select Enabled to activate each channel separately. The
settings are: Enabled and Disabled.
• IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4)
for each of the four IDE devices that the onboard IDE inter face suppor ts.
Modes 0 through 4 provide successively increased per formance. In Auto
mode, the system automatically determines the best mode for each device.
The settings are: Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4.
• IDE Primary/Secondary Master/Slave UDMA
Ultra DMA/33 implementation is possible only if your IDE hard drive suppor ts it
and the operating environment includes a DMA driver (Windows 95 OSR2 or a
third-par ty IDE bus master driver). If your hard drive and your system software
both suppor t Ultra DMA/33, select Auto to enable BIOS suppor t. The settings
are: Auto, Disabled.
• USB Controller
Select Enabled if your system contains a Universal Serial Bus (USB) controller
and you have USB peripherals. The settings are: Enabled, Disabled.
• USB Keyboard Support
Select Enabled if your system contains a Universal Serial Bus (USB) controller
and you have a USB keyboard. The settings are: Enabled, Disabled.
• USB Mouse Support
Select Enabled if your system contains a USB controller and you have a USB
Mouse.
The settings are: Enabled and Disabled.
• Init Display First
This item allows you to decide to activate whether PCI Slot or on-chip VGA first.
The settings are: PCI Slot, Onboard.
• AC97 Audio/Modem
This item allows you to decide to enable/disable the 810 chipset family to
suppor t AC97 Audio/Modem. The settings are: Enabled, Disabled.
• Onboard Audio Device (For Aureal onboard audio only)
This item allows you to enable/disable the Onboard Aureal audio chipset. The
settings are: Enabled, Disabled.
