6

I/O Por ts Connector

USB

USB por t.

IDE1

For Primar y IDE port.

IDE2

For Secondar y IDE por t.

PS/2

For PS/2 Keyboard / Mouse port.

FDD

For Floppy por t.

COMA

For Serial por t1 (COM A).

LPT

For LPT por t.

VGA

For VGA por t.

GAME

For GAME por t.

AUDIO

For MIC, LINE-IN, LINE-OUT port.

JMDM1

For Internal Modem Ring Power ON port.

1.3.

QUICK REFERENCE FOR JUMPERS &
CONNECTORS

Table 1-1

*Clear CMOS Jumper :JBAT1/J26

Pin No

Function

1-2 Close

Keep Data

2-3 Close

Clear Data

*BIOS Flash Jumper : JP3

Pin No

Function

Close

BIOS Flash Unlocked

Open

BIOS Flash Locked

*Onboard Audio Enabled/Disabled Jumper :JP4

Pin No

Function

1-2 Close

Enabled onboard audio

2-3 Close

Disabled onboard audio

She_Chp1_01-10

11/3/00, 11:05
