7
1.4 CLEAR CMOS JUMPER: JBAT1/J26
A batter y must be used to retain the mainboard configuration in CMOS RAM. Short
1-2 pins of JBAT1/J26 to store the CMOS data.
Keep Data Clear Data
1 1
3 3
2 2
J26
1 3
JBA T1
1 3
Note: You can clear CMOS by shor ting 2-3 pin, while the system is off. Then,
return to 1-2 pin position. Avoid clearing the CMOS while the system is on,
it will damage the mainboard. Always unplug the power cord from the wall
socket.
