INTEGRATED PERIPHERALS
CMOS Setup Utility - Copyright(C) 1984-1999 Award Software
Integrated Peripherals
Item Help
Menu Level >
OnChip Primary PCI IDE
Enabled
OnChip Secondary PCI IDE
Enabled
IDE Primary Master PIO
Auto
IDE Primary Slave PIO
Auto
IDE Secondary Master PIO
Auto
IDE Secondary Slave PIO
Auto
IDE Primary Master UDMA
Auto
IDE Primary Slave UDMA
Auto
IDE Secondary Master UDMA
Auto
IDE Secondary Slave UDMA
Auto
USB Controller
Enabled
USB Keyboard Support
Disabled
USB Mouse Support
Disabled
Init Display First
PCI Slot
AC97 Audio
Enabled
AC97 Modem
Disabled
Onboard Audio Device
Enabled
IDE HDD Block Mode
Enabled
Power On Function
Button Only
*KB Power On Password
Enter
*Hot Key Power On
Ctrl-F1
Onboard FDC Controller
Enabled
Onboard Serial Port 1
3F8/IRQ4
CMOS Setup Utility - Copyright(C) 1984-1999 Award Software
Integrated Peripherals
Onboard Serial Port
Disabled
*UART Mode Select
Normal
*RxD, TxD Active
Hi, Lo
*IR Transmition Delay
Enabled
Onboard Parallel Port
378/IRQ7
Parallel Port Mode
SPP
EPP Mode Select
EPP 1.7
ECP Mode use UDMA
3
PWRON After PWR-Fail
Former-sts
Game Port Address
Disabled
Midi Port Address
Disabled
Midi Port IRQ
10
Power Status LED
Dual
Item Help
Menu Level >
↑ ↓ → ←
:Move
Enter:Select
+/-/PU/PD:Value
F10:Save
ESC:Exit
F1:General Help
F5:Previous Values
F6:Fail-safe defaults
F7:Optimized defaults
↑ ↓ → ←
:Move
Enter:Select
+/-/PU/PD:Value
F10:Save
ESC:Exit
F1:General Help
F5:Previous Values
F6:Fail-safe defaults
F7:Optimized defaults
Figure 2-5: Integrated Peripherals Menu
