Page 11
xi
table of contents
Chapter 1
SYSTEM BOARD
1.1
MAINBOARD FEATURES ................................................................. 3
1.2.
MAINBOARD LAYOUT ..................................................................... 5
1.3.
QUICK REFERENCE FOR JUMPERS & CONNECTORS ......................... 6
1.4
CLEAR CMOS JUMPER: JBAT1/J26 ................................................. 7
1.4.1
BIOS FLASH JUMPER: JP3 .................................................. 8
1.4.2
CPU CORE SPEED DERIVATION PROCEDURE ........................ 9
1.4.3
OVERCLOCKING JUMPER: J2 .............................................. 9
1.5
MEMORY INSTALLATION ............................................................... 10
1.5.1
MEMORY BANK CONFIGURATION ...................................... 10
1.6
ONBOARD AUDIO ENABLED/DISABLED JUMPER: JP4 ..................... 11
1.7
CD-IN CONNECTOR: J8 ................................................................ 12
1.8
EXPANSION CARDS ..................................................................... 13
1.8.1
INSTALLING A PCI CARD ................................................... 13
