19 SKM 500 B1
GB
NOTE
► Disconnect the holder with mixing knife 9 from the blender 7 for cleaning!
► Remove the small Philips screw from the underside of the holder with mixing
knife 9.
► Rotate the blender 7 until the arrow on the blender 7 is pointing at
the symbol on the holder 9. The blender 7 can then be released from
the holder 9.
► Remove the sealing ring 8 from the holder: Slightly lift the sealing ring 8
with a fl at, blunt object (e.g. made from wood) and then carefully guide
the sealing ring 8 over the knife.
Never use sharp or pointed objects for removing the sealing ring 8!
These can damage the sealing ring 8 and therefore cause leaks!
To assemble, place the sealing ring 8 back into the holder 9 and place
the blender 7 onto the holder 9 so that the arrow
on the blender 7
is pointing at the symbol on the holder 9. Rotate the blender 7 until
the arrow is pointing at the symbol . Then screw the small Philips
screw back in again.
■ Only clean the motor block o, the power cord and the knife guard for the
cutting knife d with a damp cloth. Dry everything properly before re-using it.
■ Clean the holder with mixing knife 9 and the sealing ring 8 in warm
dishwater. Afterwards, rinse all parts with clean water so that no detergent
residue remain on the parts.
■ Clean the cutting knife t, the kneading knife r, the disk adapter e, the
shredding disk 0, the grating disk q and the cutting disk w, the emulsifying
disc 4, the lid 3 with pusher 1, the mixing bowl u, the drive shaft i, the
drive shaft adapter z, the blender 7, the blender closure 5, the blender
lid 6 and the dough scraper s in warm dishwater. Afterwards, rinse all
parts with clean water so that no detergent residue remains on the parts.
–
You can also clean these parts in the dishwasher! If possible, place the
parts in the top basket of the dishwasher. Ensure that the parts are not
trapped in any way.
■ Dry all parts thoroughly before re-using the appliance.
