AIR DELIVERY — 579F180-300 UNITS (cont)
579F216 (18 TON)
Airflow
(Cfm)
Standard Belt-Drive Motor
External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
5000 669 1.10 1019 772 1.40 1291 870 1.80 1582 963 2.10 1903 1052 2.50 2251 1137 2.90 2623
5500 717 1.40 1292 813 1.80 1585 905 2.10 1892 992 2.50 2223 1076 2.90 2680 1157 3.30 2962
6000 767 1.80 1617 858 2.20 1932 944 2.50 2256 1026 2.90 2600 1104 3.30 2967 1181 3.80 3358
6500 817 2.20 1992 903 2.60 2329 985 3.00 2673 1062 3.40 3031 1136 3.80 3410 1209 4.30 3811
7000 869 2.70 2427 950 3.10 2787 1028 3.50 3151 1102 3.90 3527 1172 4.40 3919 1241 4.80 4331
7200 889 2.94 2624 969 3.34 2993 1046 3.74 3366 1118 4.18 3749 1187 4.64 4147 1255 5.08 4564
7500 920 3.30 2919 998 3.70 3303 1073 4.10 3689 1143 4.60 4083 1210 5.00 4490 1275 5.50 4914
8000 973 3.90 3476 1047 4.30 3886 1119 4.80 4294 1186 5.30 4708 1250 5.70 5131 — — —
8500 1026 4.60 4102 1097 5.10 4635 1166 5.60 4967 — — — — — — — — —
9000 1079 5.40 4800 — — — — — — — — — — — — — — —
579F216 (18 TON) (cont)
Airflow
(Cfm)
Standard Belt-Drive Motor
External Static Pressure (in. wg)
1.3 1.4 1.6 1.8
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
5000 1178 3.15 2820 1218 3.40 3016 1295 3.80 3425 1369 4.30 3849
5500 1196 3.55 3164 1234 3.80 3366 1309 4.20 3789 1381 4.70 4229
6000 1218 4.00 3565 1251 4.20 3772 1327 4.70 4206 1396 5.20 4658
6500 1244 4.50 4022 1279 4.70 4233 1348 5.20 4677 1415 5.80 5139
7000 1275 5.05 4547 1308 5.30 4762 — — — — — —
7200 1288 5.33 4783 — — — — — — — — —
7500 1307 5.75 5135 — — — — — — — — —
8000 — — — — — — — — — — — —
8500 — — — — — — — — — — — —
9000 — — — — — — — — — — — —
LEGEND
Bhp — Brake Horsepower Input to Fan
Watts — Input Watts to Motor
NOTES:
1. Factory shipped motor drive range is 1047 to 1251 rpm. Other rpms require a
field-supplied drive.
2. Static pressure losses (i.e., economizer) must be added to external static pres-
sure before entering Air Delivery table.
3. Interpolation is permissible. Do not extrapolate.
4. Maximum continuous bhp is 5.9 and the maximum continuous watts are 5180.
Extensive motor and drive testing on these units ensures that the full horse-
power range of the motor can be utilized with confidence. Using your fan mo-
tors up to the watts rating shown will not result in nuisance tripping or
premature motor failure. Unit warranty will not be affected.
579F240 (20 TON)
Airflow
(Cfm)
Standard Belt-Drive Motor
External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
6000 767 1.80 1617 858 2.20 1932 944 2.50 2256 1026 2.90 2600 1104 3.30 2967 1181 3.80 3358
6500 817 2.20 1992 903 2.60 2329 985 3.00 2673 1062 3.40 3031 1136 3.80 3410 1209 4.30 3811
7000 869 2.70 2427 950 3.10 2787 1028 3.50 3151 1102 3.90 3527 1172 4.40 3919 1241 4.80 4331
7500 920 3.30 2919 998 3.70 3303 1073 4.10 3689 1143 4.60 4083 1210 5.00 4490 1275 5.50 4914
8000 973 3.90 3476 1047 4.30 3886 1119 4.80 4294 1186 5.30 4708 1250 5.70 5131 1313 6.20 5569
8500 1026 4.60 4102 1097 5.10 4635 1166 5.60 4967 1231 6.00 5401 1292 6.50 5843 1352 7.00 6297
9000 1079 5.40 4800 1147 5.90 5257 1214 6.40 5714 1276 6.90 6171 1336 7.40 6632 1393 7.90 7102
9500 1133 6.20 5576 1199 6.80 6058 1263 7.30 6540 1323 7.90 7018 1381 8.40 7500 1436 8.90 7988
10,000 1188 7.20 6432 1250 7.80 6939 1313 8.30 7444 1371 8.90 7946 1426 9.50 8449 — — —
579F240 (20 TON) (cont)
Airflow
(Cfm)
Standard Belt-Drive Motor
External Static Pressure (in. wg)
1.4 1.6 1.8 1.9 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
6000 1255 4.20 3772 1327 4.70 4206 1396 5.20 4658 1431 5.45 4884 1465 5.70 5110
6500 1279 4.70 4233 1348 5.20 4677 1415 5.80 5139 1449 6.10 5370 1482 6.40 5601
7000 1308 5.30 4762 1373 5.80 5215 1437 6.40 5686 1469 6.70 5922 1501 7.00 6157
7500 1339 6.00 5356 1401 6.50 5818 1462 7.00 6298 1493 7.25 6538 1523 7.50 6778
8000 1373 6.70 6024 1433 7.30 6495 1493 7.80 6966 1523 8.05 7202 — — —
8500 1410 7.60 6765 1467 8.10 7248 1524 8.70 7731 — — — — — —
9000 1449 8.50 7584 1503 9.00 8033 — — — — — — — — —
9500 1488 9.40 8403 — — — — — — — — — — — —
10,000 — — — — — — — — — — — — — — —
LEGEND
Bhp — Brake Horsepower Input to Fan
Watts — Input Watts to Motor
NOTES:
1. Boldface indicates additional capability of the 460-v motor.
2. Factory shipped motor drive range is 1238 to 1494 rpm. Other rpms require a
field-supplied drive.
3. Static pressure losses (i.e., economizer) must be added to external static pres-
sure before entering Air Delivery table.
4. Interpolation is permissible. Do not extrapolate.
5. Maximum continuous bhp is 8.7 for 208/230 and 575-v units and 9.5 for 460-v
units. The maximum continuous watts are 7915 for the 208/230 and 575-v units
and 8640 for the 460-v units. Extensive motor and drive testing on these units
ensures that the full horsepower range of the motor can be utilized with confi-
dence. Using your fan motors up to the watts rating shown will not result in nui-
sance tripping or premature motor failure. Unit warranty will not be
affected.
