SPECIFICATIONS — 579F180-300
UNIT SIZE
180
216
240
300
208/230, 460 v
575 v
NOMINAL CAPACITY (tons)
15
18
20
25
OPERATING WEIGHT (lb)
Unit
Al/Al*
1604/1624
1850
1850/2031
2234/2413
Economizer
110
110
110
110
Roof Curb††
200
200
200/213
200/213
COMPRESSOR
Semi-Hermetic
Hermetic
Semi-Hermetic
Quantity
1
2
2
2
Oil (oz)
115
65 ea
65 ea
152 ea
REFRIGERANT TYPE
R-22
Operating Charge (lb-oz)¶
Circuit 1
19-4
15-4
15-8
16-12
Circuit 2
—
12-6
15-8
15-12
CONDENSER COIL
Enhanced Copper Tubes, Aluminum Lanced Fins
Rows...Fins/in.
2...17
3...15
4...15
4...15
Total Face Area (sq ft)
17.9
22.2
22.2
22.2
CONDENSER FAN
Propeller Type
Nominal Cfm
10,500
14,200
14,200
Quantity...Diameter (in.)
3...22
2...30
2...30
Motor Hp...Rpm
1
⁄
2
...1050
1...1075
1...1075
Watts Input (Total)
1100
3400
3400
EVAPORATOR COIL
Copper Tubes, Aluminum or Copper Plate Fins
Rows...Fins/in.
2...17
3...17
4...15
4...15
Total Face Area (sq ft)
17.9
17.9
17.9
17.9
EVAPORATOR FAN
Centrifugal Type
Quantity...Size (in.)
2...10 x 10
2...10 x 10
2...12 x 12
2...12 x 12
2...12 x 12
Type Drive
Belt
Belt
Belt
Belt
Belt
Nominal Cfm
6000
6000
7200
8000
10,000
Motor Hp
3.7
3.0
5
7
1
⁄
2
10
Maximum Continuous Bhp
4.25
3.45
5.90
8.7 [208/230,575 v]
9.5 [460 v]
10.2 [208/230,575 v]
11.8 [460 v]
Motor Frame Size
56H
56H
184T
213T
215T
Fan Rpm Range
1194-1526
1201-1462
1047-1251
1238-1494
1323-1579
Motor Bearing Type
Ball
Ball
Ball
Ball
Ball
Maximum Allowable Rpm
1550
1550
1550
1550
1550
Motor Pulley Pitch Diameter Min/Max (in.)
3.4/4.4
4.3/5.3
4.9/5.9
5.4/6.4
5.8/7.0
Nominal Motor Shaft Diameter (in.)
7
⁄
8
7
⁄
8
1
1
⁄
8
1
3
⁄
8
1
3
⁄
8
Fan Pulley Pitch Diameter (in.)
5.0
6.4
8.4
7.9
7.9
Nominal Fan Shaft Diameter (in.)
1
3
⁄
16
1
3
⁄
16
1
7
⁄
16
1
7
⁄
16
1
7
⁄
16
Belt, Quantity...Type...Length (in.)
1...AX...42
1...BX...45
1...BX...50
1...BX...50
1...BX...51
Pulley Center Line Distance (in.)
13.5-15.5
13.5-15.5
13.3-14.8
14.6-15.4
14.6-15.4
Speed Change per Full Turn of
Movable Pulley Flange (rpm)
66
52
34
43
43
Movable Pulley Maximum Full Turns
From Closed Position
5
5
6
6
6
Factory Setting
3.5
3.5
3
3
3
Factory Speed Setting (rpm)
1294
1279
1149
1366
1451
Fan Shaft Diameter at Pulley (in.)
1
3
⁄
16
1
3
⁄
16
1
7
⁄
16
1
7
⁄
16
1
7
⁄
16
(Table continued on next page.)
LEGEND
Al
— Aluminum
Bhp
— Brake Horsepower
FIOP — Factory-Installed Option
*Evaporator coil fin material/condenser coil fin material.
†Rollout switch is manual reset.
**Requires the accessory controls upgrade kit.
††Weight of 14-in. roof curb.
Low-heat weight/high-heat weight.
¶Circuit 1 consists of lower portion of condenser coil and lower portion of evaporator coil, and Circuit 2 is the upper
portion of both coils.
***The 579F300 unit requires 2-in. industrial-grade filters capable of handling face velocities of up to 625 ft/min.
NOTE: The 580D036-150 units have a loss-of-charge/low-pressure switch (accessory) located in the liquid line. The
579F180-300 units have a low-pressure switch (standard) located on the suction side.
