AIR DELIVERY — VERTICAL DISCHARGE UNITS (cont)
580D120 (10 TON)
Airflow
(Cfm)
Standard and Alternate Belt Drive Motors
External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
3000 592 0.76 723 661 0.93 859 722 1.09 989 779 1.26 1131 829 1.42 1267 880 1.58 1404
3100 607 0.83 779 676 1.01 924 734 1.17 1056 791 1.34 1199 840 1.51 1344 890 1.68 1491
3200 622 0.90 835 690 1.09 989 746 1.25 1123 803 1.43 1275 852 1.60 1422 900 1.77 1569
3300 638 0.98 899 705 1.17 1056 759 1.33 1190 815 1.52 1353 864 1.70 1508 910 1.88 1665
3400 653 1.06 965 719 1.26 1131 772 1.43 1275 826 1.62 1439 876 1.81 1604 921 1.98 1753
3500 669 1.15 1039 733 1.35 1207 786 1.53 1361 838 1.72 1526 888 1.91 1691 933 2.10 1858
3600 684 1.24 1114 747 1.44 1284 800 1.64 1456 850 1.82 1613 900 2.03 1796 945 2.22 2014
3700 700 1.33 1190 760 1.54 1370 814 1.75 1552 863 1.92 1700 912 2.14 1892 957 2.34 2117
3800 715 1.43 1275 774 1.64 1456 828 1.86 1648 875 2.04 1805 924 2.26 1997 969 2.47 2230
3900 731 1.54 1370 787 1.74 1543 843 1.98 1753 888 2.16 1910 936 2.38 2151 981 2.60 2344
4000 747 1.64 1456 801 1.85 1639 857 2.10 1858 902 2.30 2032 948 2.51 2265 993 2.74 2469
4100 763 1.76 1560 816 1.97 1744 872 2.23 1971 916 2.44 2203 960 2.64 2380 1005 2.88 2596
4200 778 1.88 1665 831 2.10 1884 886 2.36 2084 929 2.58 2326 972 2.78 2505 1016 3.03 2735
4300 794 2.00 1770 846 2.23 1971 900 2.50 2256 943 2.73 2460 985 2.93 2642 1028 3.17 2866
4400 810 2.13 1884 861 2.37 2093 913 2.64 2380 958 2.89 2605 999 3.09 2791 1040 3.32 3010
4500 826 2.27 2006 876 2.52 2273 927 2.78 2505 973 3.04 2744 1012 3.26 2952 — — —
4600 842 2.41 2177 892 2.67 2406 940 2.92 2633 987 3.21 2904 — — — — — —
4700 858 2.55 2300 907 2.83 2551 954 3.08 2782 1002 3.38 3068 — — — — — —
4800 874 2.70 2433 922 2.99 2698 968 3.24 2933 — — — — — — — — —
4900 890 2.86 2578 938 3.16 2857 — — — — — — — — — — — —
5000 906 3.03 2735 953 3.33 3020 — — — — — — — — — — — —
580D120 (10 TON) (cont)
Airflow
(Cfm)
Standard and Alternate Belt Drive Motors
External Static Pressure (in. wg)
1.4 1.6 1.8 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
3000 924 1.73 1534 970 1.89 1736 1019 2.00 1828 1066 2.30 2082
3100 935 1.84 1695 977 2.00 1828 1026 2.17 1971 1070 2.44 2203
3200 946 1.95 1786 987 2.11 1920 1029 2.28 2065 1075 2.51 2265
3300 957 2.06 1878 998 2.23 2022 1037 2.40 2169 1082 2.58 2326
3400 967 2.17 1971 1009 2.35 2125 1047 2.53 2282 1087 2.70 2433
3500 976 2.29 2074 1020 2.48 2238 1058 2.66 2397 1095 2.84 2560
3600 986 2.41 2177 1030 2.61 2353 1069 2.80 2523 1106 2.98 2688
3700 998 2.54 2291 1039 2.74 2469 1081 2.94 2651 1117 3.13 2829
3800 1010 2.67 2406 1049 2.87 2587 1091 3.08 2782 1128 3.29 2981
3900 1022 2.81 2533 1060 3.02 2726 1100 3.23 2923 — — —
4000 1034 2.96 2670 1072 3.17 2866 1110 3.38 3068 — — —
4100 1046 3.11 2810 1084 3.32 3010 — — — — — —
4200 1058 3.26 2952 — — — — — — — — —
4300 — — — — — — — — — — — —
4400 — — — — — — — — — — — —
4500 — — — — — — — — — — — —
4600 — — — — — — — — — — — —
4700 — — — — — — — — — — — —
4800 — — — — — — — — — — — —
4900 — — — — — — — — — — — —
5000 — — — — — — — — — — — —
LEGEND
Bhp — Brake Horsepower Input to Fan
Watts — Input Watts to Motor
NOTES:
1. Boldface indicates field-supplied drive required. (See Note 6.)
2. indicates alternate motor and/or drive required.
3. indicates field-supplied motor and drive required.
4. indicates maximum usable bhp/watts of standard motor and drive.
5. indicates maximum usable bhp/watts of alternate motor and/or drive.
6. Standard drive range is 685 to 935 rpm. Alternate drive range is 835 to
1085 rpm. All other rpms require a field-supplied drive.
7. Values include losses for filters, unit casing, and wet coils.
8. Maximum continuous bhp is 2.4 for the standard motor and 2.9 for the alter-
nate motor. Maximum continuous watts are 2120 for the standard motor and
2615 for the alternate motor. Extensive motor and electrical testing on these
units ensures that the full range of the motor can be utilized with confidence.
Using your fan motors up to the wattage ratings shown will not result in nui-
sance tripping or premature motor failure. Unit warranty will not be affected.
See Evaporator-Fan Motor Performance table on page 60 for additional
information.
9. Use of a field-supplied motor may affect wire sizing. Contact your local rep-
resentative to verify.
10. Interpolation is permissible. Do not extrapolate.
11. Minimum allowable cfm is 300 cfm/ton.
