Bryant 579F User Manual
Page 10
DIMENSIONAL DRAWING — 579F240,300
UNIT
579F
CORNER WEIGHT*
DIMENSIONS
A
B
C
D
A
B
C
D
E
Lb
Kg
Lb
Kg
Lb
Kg
Lb
Kg
Ft-in.
mm
Ft-in.
mm
Ft-in.
mm
Ft-in.
mm
Ft-in.
mm
240 270
495
225
483
219
362
164
511
232
3-3
991
3-7
1092
0-3
76
6-11
1
⁄
2
2121
1-7
13
⁄
16
504
240 485
431
196
421
191
494
224
685
311
4-2
1270
3-4
1016
0-4
1
⁄
2
114
8- 7
1
⁄
4
2623
3-3
5
⁄
8
1006
300 270
523
237
541
245
574
260
596
270
3-3
991
3-7
1092
0-3
76
6-11
1
⁄
2
2121
1-7
13
⁄
16
504
300 485
465
211
486
220
725
329
737
334
4-2
1270
3-5
1041
0-4
1
⁄
2
114
8- 7
1
⁄
4
2623
3-3
5
⁄
8
1006
*Weights are for unit only and do not include options or crating.
UNIT
579F
MAXIMUM SHIPPING
WEIGHT
Lb
Kg
240 270
2131
967
240 485
2311
1048
300 270
2514
1140
300 485
2693
1222
NOTES:
1. Dimensions in (
) are in millimeters.
2.
Center of gravity.
3.
Direction of airflow.
4. Ductwork to be attached to accessory roof curb only.
5. Minimum clearance:
a. Rear: 7
Ј
0
Љ
(2134) for coil removal. This dimension
can be reduced to 4
Ј
0
Љ
(1219) if conditions permit
coil removal from the top.
b. 4
Ј
0
Љ
(1219) to combustible surfaces, all four sides
(includes between units).
c. Left side: 4
Ј
0
Љ
(1219) for proper condenser coil
airflow.
d. Front: 4
Ј
0
Љ
(1219) for control box access.
e. Right side: 4
Ј
0
Љ
(1219) for proper operation of
damper and power exhaust (if so equipped).
f. Top: 6
Ј
0
Љ
(1829) to assure proper condenser fan
operation.
g. Bottom: 14
Љ
(356) to combustible surfaces (when not
using curb).
h. Control box side: 3
Ј
0
Љ
(914) to ungrounded surfaces
(non-combustible).
i. Control box side: 3
Ј
6
Љ
(1067) to block or concrete
walls, or other grounded surfaces.
j. Local codes or jurisdiction may prevail.
6. With the exception of clearance for the condenser coil
and the damper/power exhaust as stated in Note No. 5,
a removable fence or barricade requires no clearance.
7. Dimensions are from outside of corner post. Allow
0
Ј
-
5
⁄
16
Љ
(8) on each side for top cover drip edge.
10
