5. COVERS
PR99057
REF.NO.
CODE
Q'TY
DESCRIPTION
SYMBOL
REMARK
1
UL7983001
1 MAIN COVER ASSY
2
085411215
1 TAPTITE, BIND B M4X12
3
085411215
1 TAPTITE, BIND B M4X12
4
085411215
1 TAPTITE, BIND B M4X12
5
002400616
3 SCREW PAN M4X6
6
087320616
2 TAPTITE, CUP S M3X6
7
0A5350605
1 SCREW PAN(WASHER), M3.5X6
8
UL8659001
1 EL PCB UNIT
B48K304
9
UL8753001
1 MAIN FAN MOTOR
10
UL8509001
1 SUB FAN MOTOR
11
085411215
2 TAPTITE, BIND B M4X12
12
UL8505001
1 BASE PLATE 820/1020/1040
12
UL8601001
1 BASE PLATE 1050
13
UL8506001
1 MAIN PCB GUIDE RAIL (820/1020/1040)
14
UL8507001
2 RUBBER FOOT
CHNG
15
085411215
8 TAPTITE, BIND B M4X12
16
087320616
5 TAPTITE, CUP S M3X6
17
UL8508001
1 INSULATION SHEET
18
UL8512001
1 INLET HOLDER
19
085411215
1 TAPTITE, BIND B M4X12
20
UL8510001
1 I/F SHIELD ASSY 820/1020/1040
20
UL8604001
1 I/F SHIELD ASSY 1050
21
UL8518001
1 PANEL COVER, GRAY1227
22
UL8745001
1 TOP COVER ASSY
23
UL8515001
1 OUTPUT TRAY
24
UL8516001
1 EXTENSION SUPPORT WIRE
25
UL8746001
1 REAR COVER ASSY
26
085411215
2 TAPTITE, BIND B M4X12
27
UL6740001
1 LASER CAUTION LABEL
27
UL7931001
1 LASER CAUTION LABEL (LEGEND)
28
UL6741001
1 TONER WARNING LABEL
29
UL8575001
1 MODEL PLATE, HL-820
29
UL8639001
1 MODEL PLATE, HL-1020
29
UL8519001
1 MODEL PLATE, HL-1040
29
UL8641001
1 MODEL PLATE, HL-1040DX
29
UL8686001
1 MODEL PLATE, HL-1040 (LEGEND)
29
UL8611001
1 MODEL PLATE, HL-1050
29
UL8645001
1 MODEL PLATE, HL-1050DX
29
UL8820001
1 MODEL PLATE, HL-1050 (LEGEND)
30
UL8640001
1 MYLAR LABEL, HL-1020 CAN
30
UL8650001
1 MYLAR LABEL, HL-820 EUR
30
UL8522001
1 MYLAR LABEL, HL-1040 US
30
UL8547001
1 MYLAR LABEL, HL-1040 CAN
30
UL8642001
1 MYLAR LABEL, HL-1040DX CAN
30
UL8651001
1 MYLAR LABEL, HL-1040 EUR
30
UL8612001
1 MYLAR LABEL, HL-1050 US
30
UL8596001
1 MYLAR LABEL, HL-1050 CAN
30
UL8646001
1 MYLAR LABEL, HL-1050DX CAN
30
UL8652001
1 MYLAR LABEL, HL-1050 EUR
31
UH3297001
1 C-TICK MARK LABEL
32
UH0905001
1 US PATENT SEAL HL-10
33
UG3005000
4 FERRITE CORE
34
UG3005000
7 FERRITE CORE (HL1050)
35
UK3617000
1 CORE, TFC-16813 (HL1050)
MODEL HL-820/1020/1040/1050 84U-821/831/832/861/862-060
T/I NO. PR98096 / PR98110 / PR98176 / PR99041 / PR99057
