HL1060PL
5. FIXING UNITS
PR99042
REF.NO.
CODE
Q'TY DESCRIPTION
REMARK
1-9
UH3164001
1 FIXING UNIT Y, 120V (SP)
1-9
UH3165001
1 FIXING UNIT Y, 230V (SP)
1
UH3306001
1 HALOGEN LAMP Y, 120V (SP)
1
UH3307001
1 HALOGEN LAMP Y, 230V (SP)
2
087411616
2 TAPTITE, CUP B M4X16
3
UL6667001
1 THERMISTOR ASSY
CHNG
4
UH3188001
1 CLEANER ASSY Y
5
UH3178000
2 H/R BEARING Y
6
UH3419001
1 HEAT ROLLER YS ASSY
7
087311415
1 TAPTITE, CUP B 3X14
8
UH3323001
4 EJECT PINCH ROLLER ASSY
9
UL6682001
4 PINCH SPRING
MODEL HL-1060 54U-S01-051
T/I NO. PR98040 / PR98292 / PR99042
7. MAIN PCB
REF.NO.
CODE
Q'TY DESCRIPTION
SYMBOL
REMARK
1
UK3439001
1 MAIN PCB ASSY, PCL5 2M(SP)
B48K246-300J
MODEL HL-1060 54U-S01-101
T/I No. 97-P028 / 97-P043 / PR97161
