5. FIXING UNITS
PR99042
REF.NO.
CODE
Q'TY
DESCRIPTION
REMARK
1-9
UH3164001
1 FIXING UNIT Y, 120V (SP)
1-9
UH3165001
1 FIXING UNIT Y, 230V (SP)
1
UH3306001
1 HALOGEN LAMP Y, 120V (SP)
1
UH3307001
1 HALOGEN LAMP Y, 230V (SP)
2
087411616
2 TAPTITE, CUP B M4X16
3
UL6667001
1 THERMISTOR ASSY
CHNG
4
UH3188001
1 CLEANER ASSY Y
5
UH3178000
2 H/R BEARING Y
6
UH3419001
1 HEAT ROLLER YS ASSY (SP)
7
087311415
1 TAPTITE, CUP B 3X14
8
UH3323001
4 EJECT PINCH ROLLER ASSY
9
UL6682001
4 PINCH SPRING
MODEL HL-1070 54U-S03-050/051
T/I NO. PR98292 / PR99042
7. MAIN PCB
REF.NO.
CODE
Q'TY
DESCRIPTION
SYMBOL
REMARK
1
UK3950001
1 MAIN PCB ASSY
B48K302-100C
2
UH3542001
1 CONDUCTIVE TAPE
MODEL HL-1070 54U-S03-101
T/I NO. PR98108
