5.2.1.1 Check Monitor Power

Step 1:

Make sure the monitor is turned on.

Step 2:

Check the power source for the monitor.

Step 3:

Make sure the power source has the correct power rating (check panel

specifications for details).

Step 4:

Make sure the LCD panel power cables are properly secured to the monitor and

to the power source.

5.2.1.2 Check Monitor Video Connection

Make sure the video cable is linkedproperly.

Step 1:

Make sure a working DVIcablewith length less than 5 M is connected to

iVW-UD322.

Step 2:

Fasten the screws on the connector of video cable.

5.2.2 No Image on Two or More Monitors

If there is no image on more than one of the panels, then repeat the steps in Section 5.2.1

for all of the monitors in the array.

5.2.3 No Image on Any Monitor

If no image displays on any monitors, repeat the steps in Section 5.2.1 for all the monitors

in the array, then try the following additional steps.

5.2.3.1 Check Video Wall Controller Power

Make sure that the controller is powered on.

Step 1:

Ensure the power supply is connected to the power source.

Step 2:

Make sureiVW-UD322 is connected to the power adaptor.
