iVW-UD322iVW-UD322 Video Wall Controller
18
Mode
Input
Resolution
Output
Resolution
Vertical
Hz
Monitor Ratio / Notes
1280x3072
1280x1024
60
5:4
1360x2304
1360x768
60
16:9
1366x2304
1366x768
60
16:9
3.7 Setting Video Wall Controller and Graphics Card Resolution
To setup the resolution on the graphics card and on the video wall controller, follow the
instructions below.
Step 3:
Turn on the video wall controller.
Step 4:
Turn on the computer.
Step 5:
The computer will automatically detect the video wall controller as a display.
Step 6:
Set the required output resolution on the video wall controller
Step 7:
Check the input resolution on the video wall controller and look up in the
setting table above. If the resolution is not listed, then correct the settings
manually to the nearest mode in the display mode list as shown in the section
below.
S
te
p
0
:
3.7.1 Setting Adjustment Troubleshooting (Manual Adjustment)
If the graphics card settings do not adjust automatically after adjusting the video wall
controller, follow these steps to fix the problem.
Step 1:
Restart the computer. Some graphics cards don't support the correct detection
on the video wall controllerconnected at runtime and a system restart is
required.
Step 2:
After restarting, check the output resolution. Right-click on the desktop and
select "Properties".
