iVW-UD322iVW-UD322 Video Wall Controller
44
On
The value of X and the value of Y can be adjusted to compensate for
gaps between monitors (for single controller)
MR
The right side is fixed and the left side changes when adjustments
are made (for right side controller in the dual controller configuration)
ML
The left side is fixed and the right side changes when adjustments
are made (for left side controller in the dual controller configuration)
MU
The top side is fixed and the bottom side changes when adjustments
are made (for top side controller in the dual controller configuration)
MD
The bottom side is fixed and the top side changes when adjustments
are made (for bottom side controller in the dual controller
configuration)
Mask X and Y Setting
Adjusts the horizontal (X) and vertical (Y) mask settings.
