iVW-UD322iVW-UD322 Video Wall Controller
23
Menu Options Description
Slave Mask Setting
(Note: These settings
can only be changed
while Link function is
turned off and Scan
function is turned on)
DVI DVI 1-4: Update linked slave controllers’
settings
DVI x: Update setting for an individual slave
controller when link is off.
X Setthe horizontal mask value
Y Setthe vertical mask value
Settings OUT Set the output resolution
MODE Set the output mode
Warning Change
Setting
Warns that the output resolution on the
video source must be changed.
Information OUT Shows the output resolution
IN Shows the input resolution
Sync and Power No SYNC
Pwr Off
Time to enter stand-by mode when there is
no video signal input
SYNC Enable/disablethe synchronization between
video wall controllers with fiber optical cable.
(iVW-UD322F only)
SCAN Toggles the scan function between the
master video wall controller and the slave
video wall controllers
Version Information FPGA Version number of one FPGA chip
CPLD Version number of the CPLD chip
FW Firmware version number
Model information Name Displays the model name
SN Displays the serial number
Table 4-1: OSD Menu Structure
