iVW-UD322iVW-UD322 Video Wall Controller
4
Figure 1-3: iVW-UD322 Rear Panel
1.5 Technical Specifications
Video box features are listed in Table 1-1. See Chapter 2 for details.
Specification Detail
Model Name iVW-UD322
Main Features 1. Multiple viewing modes
2. Software OSD
3. Remote control (optional)
4. Bezel masking
Inputs 1 x Dual-link DVI-D
Outputs 4 x Single-link DVI-D
Dimensions (W x D x H) 230 mm x 180 mm x 47 mm
Cooling Fanless
Input Resolution See Section 3.6: Resolution and Display Mode Charts
Output Resolution See Section 3.6: Resolution and Display Mode Charts
Power Adapter Input 90 VAC to 264 VAC / 47 Hz to 63 Hz
Power Adapter Output 12V, 3.33A, 40W
Safety and Emission CE, FCC
