a.

Release

the

latch

on

the

drive

CRU

by

pinching

together

the

blue

line

on

the

tray

latch

and

the

finger

hole

on

the

tray

handle,

as

shown

by

the

arrow

in

b.

Pull

the

tray

handle

out

into

the

open

position.

c.

Lift

the

drive

CRU

partially

out

of

the

bay.

d.

To

avoid

possible

damage

to

the

drive,

wait

at

least

70

seconds

before

fully

removing

the

drive

CRU

from

the

storage

server

to

allow

the

drive

to

stop

(spin

down).

e.

Verify

that

there

is

proper

identification

(such

as

a

label)

on

the

drive

CRU,

and

then

slide

it

completely

out

of

the

storage

server.

3.

Install

the

new

drive

CRU:

a.

Gently

push

the

drive

CRU

into

the

empty

bay

until

the

hinge

of

the

tray

handle

latches

beneath

the

storage

server

bezel.

b.

Push

the

tray

handle

down

into

the

closed

(latched)

position.

4.

Check

the

drive

LEDs:

v

When

a

drive

is

ready

for

use,

the

green

Activity

LED

is

either

on

continuously

or

rapidly

flashing,

and

the

amber

Fault

LED

is

off.

v

If

the

amber

Fault

LED

lights

and

is

not

flashing,

remove

the

drive

from

the

unit

and

wait

10

seconds;

then,

install

the

drive

again.

5.

If

the

drive

is

part

of

a

defined

RAID

array,

the

array

reconstruction

(without

hot-spare)

or

copy-back

(with

hot-spare)

operation

automatically

starts.

6.

Use

the

DS4000

Storage

Manager

software

GUI

to

verify

that

the

drive

is

shown

in

the

Storage

Subsystem

Management

window.

Upgrading

drives

You

can

upgrade

drives

in

the

following

two

ways:

v

By

adding

drives

to

empty

slots

in

the

storage

server

(see

v

By

replacing

existing

drives

with

larger

capacity

drives

Adding

larger-capacity

drives

This

section

provides

guidelines

for

upgrading

the

drives

in

the

storage

server.

Read

the

software

documentation

and

this

entire

section

to

determine

if

you

should

use

this

procedure,

use

a

modified

version

of

this

procedure,

or

use

a

different

procedure

that

is

provided

by

your

operating

system.

Instructions

that

are

provided

with

your

software

should

supersede

anything

stated

in

this

document.

Attention:

After

you

remove

a

drive

CRU,

wait

at

least

70

seconds

before

replacing

or

reseating

the

drive

CRU

to

allow

the

drive

to

properly

spin

down.

Failure

to

do

so

may

cause

undesired

events.

There

are

two

methods

for

upgrading

drives:

v

Replacing

all

the

drives

at

the

same

time

This

method

requires

that

you

back

up

the

data

on

the

affected

drives

and

then

turn

off

the

storage

server.

After

replacing

all

the

drives,

you

must

reconfigure

the

new

drives

and

restore

data

from

backup.

See

the

procedure

in

This

is

the

safest

way

to

exchange

drives

without

losing

data.

However,

this

method

might

take

a

long

time

to

complete

because

of

the

backup,

reconfiguration,

and

restoration

processes.

In

addition,

other

users

are

not

able

Chapter

5.

Installing

and

replacing

components

83
