Chapter 9 Trunking
ES-1528 User’s Guide
68
Figure 34 Trunk Setting
The following table describes the labels in this screen.
Table 15 Trunking: Configuration
LABEL DESCRIPTION
Distribution
Criterion
Trunking uses a distribution algorithm to balance traffic between trunk members.
Select the traffic distribution algorithm between trunk member ports. Your choices are:
•
SA (Source MAC Address)
• DA (Destination MAC Address)
• SA + DA
Modify Trunk
Group
Member
Configure the following settings to create and modify trunk groups.
Trunk id Select the trunk you want to modify or select a trunk id which is not yet configured to
create a new trunk group.
Port Select the port you want to add or delete.
Add Click this to add the port to the trunk group you selected in the Trunk id field.
Del Click this to delete the port from the trunk group you selected in the Trunk id field.
Trunk 1 ...
Trunk 6
This summary table lists all the trunks. Trunk Group Member column indicates which
ports are members of the trunk group.
Apply Click Apply to save your changes to the switch.
