Chapter 4 The Web Configurator
ES-1528 User’s Guide
46
Statistics
Use these screen to view system statistics such as the number of packets received
on the switch, collisions and errors and to view statistics for individual ports on the
switch.
VLAN
Use these screens to create new IEEE 802.1Q VLANs as well as view the status
and edit existing IEEE 802.1Q VLANs on the switch.
Trunk Groups
Use these screens to create trunk groups and add/remove ports from existing trunk
groups.
Mirror
Use this screen to copy traffic from one port or ports to another port in order that
you can examine the traffic from the first port without interference.
QoS
Use these screens to configure queuing with associated queue weights for the
switch.
Rate
Use these screens to specify bandwidth limits and storm control limits for the
switch.
Port Rate
Use this screen to cap the maximum bandwidth allowed from specified source(s) to
specified destination(s).
Storm
Control
Use this screen to cap the rate of broadcast, multicast and unknown unicast
packets the switch will allow on individual ports.
L2 Address
Use these screens to view and manage the MAC address table.
Management Use this screen to add, delete or look up MAC addresses in the MAC address
table.
Display
Use this screen to view the entries in the MAC address table.
Cable Diagnostic Use this screen to perform cable testing on individual ports.
Auto DoS
Use these screens to activate security features against Denial of Service (DoS)
attacks.
Auto VoIP
Use these screens to configure settings that automatically give higher priority to
Voice over Internet Protocol (VoIP) traffic.
Logging
Use these screens to configure log settings and view system logs.
Settings
Use this screen to configure which events the switch should log.
RAM Logs
Use this screen to configure logs which are saved to volatile memory. These logs
are cleared when the switch is rebooted.
Flash Logs
Use this screen to configure logs which are saved to non-volatile memory. You can
view these logs even after a switch is rebooted.
SNMP
Use these screens to configure SNMP management settings.
Engine ID
Use this screen to configure SNMP engine ID.
Group
Use this screen to configure groups with different access rights for SNMP
management.
User
Use this screen to create users and assign them to pre-defined SNMP groups.
Community
Use this screen to define security parameters for SNMP v1 and SNMP v2c.
Trap Station
Use this screen to configure settings that define when notifications are sent to an
external management station.
RMON-Lite
Use this screen to configure Remote Network Monitoring Management Information
Base (RMON MIB) settings.
Dynamic ARP
Use these screens to enable and configure ARP table settings.
Settings
Use this screen to configure ARP table settings.
Table 4 Navigation Panel Links (continued)
LINK
DESCRIPTION
