Chapter 18 SNMP
ES-1528 User’s Guide
111
The following table describes the labels in this screen.
18.3.2 SNMP User - Modify
Click on the User ID number or select a User ID from the User ID drop down list box in the
SNMP User screen to modify the settings of an existing user.
Figure 64 SNMP User - Modify
The following table describes the labels in this screen.
Table 44 SNMP User - Create
LABEL DESCRIPTION
User Name Specify the name for this SNMP user.
Group Name Specify the SNMP group this user belongs to.
SNMP Version Specify the SNMP version this group uses to manage the switch.
Auth Type Authentication can only be configured for SNMP v3.
Select None to allow this user to manage the switch without authentication or select
MD5 and configure the Key field to force this user to authenticate with the switch.
Key Enter the MD5 key this user must use to authenticate with the switch.
Create Click this to add this SNMP user to the switch.
Cancel Click this to go back to the main SNMP Group screen without saving your changes.
Table 45 SNMP User - Modify
LABEL DESCRIPTION
User ID This field indicates which user you are modifying.
Click on Remove This User to delete this user configuration from the switch.
Click on Display All User to view the main SNMP User screen.
User Name Edit the name for this SNMP user.
Group Name Select the SNMP group this user should belong to.
SNMP Version Specify the SNMP version this group uses to manage the switch.
Auth Type Authentication can only be configured for SNMP v3.
Select None to allow this user to manage the switch without authentication or select
MD5 and configure the New Key field to force this user to authenticate with the
switch.
