Chapter 20 Dynamic ARP
ES-1528 User’s Guide
135
Figure 85 Viewing ARP Table Entries
The following table describes the labels in this screen.
20.4 Adding ARP Table Entries
Click ADD in the Dynamic ARP > ARP Entries screen to open the Add Static MAC-IP
binding screen. Use this screen to add entries to the ARP table.
"
You must first enable dynamic ARP in the Dynamic ARP > Settings screen
before you can add static ARP table entries.
Figure 86 Viewing ARP Table Entries
Table 66 ARP Table
LABEL DESCRIPTION
Static MAC-IP
binding: ADD
This field is only available when you enable dynamic ARP in the Dynamic ARP >
Settings screen. Click ADD to add a static entry to the ARP table. See Section 20.4
on page 135 .
Item This is the ARP table entry number.
MAC Address This is the MAC address of the device connected to the switch with the corresponding
IP address below.
IP Address This is the learned IP address of a device connected to a switch port with
corresponding MAC address above.
VLAN This is the VLAN number of the device connected to the switch.
Type This shows whether the MAC address is dynamic (learned by the switch) or static
(manually entered in the Add Static MAC-IP binding screen).
DELETE Click this to remove this ARP table entry.
