5.2.2. Accessing the Text Interface
The Text Interface can be accessed via Network, modem or local PC. In order
to access the Text Interface, your installation must include the following:
• Access Via Network: The CMS-6R4 must be connected to your TCP/IP
Network, and your PC must include a communications program (such as
Hyperterminal™.)
• Access Via Modem: A phone line must be connected to the CMS-6R4's
Modem Port. Your PC Must include a communications program (such as
Hyperterminal™.)
• Access Via Local PC: Your local PC must be connected to a CMS-6R4
RS232 COM Port. The local PC must include a communications program
(such as Hyperterminal™.)
To access command mode via the Text Interface, proceed as follows:
1. The CMS-6R4 is transparent to parity and will accept 7 or 8 bit
characters, but will always answer back at 8 bits, no parity. Make certain
your communication program is set for the appropriate baud rate, bits,
parity and Communications Port.
a) Via Modem: Start your communications program. Dial the number
for the line connected to the CMS-6R4's Phone Line port. Wait for
the Connect message, then proceed to Step 2.
b) Via Local PC: Start your communications program and press
[Enter]. Wait for the connect message, then proceed to Step 2.
CMS-6R4 v1.00 Site ID: (undefined)
PORT | NAME | CMD ACCESS | STATUS | MODE | BUFFER COUNT
-----+------------------+----------------+--------+---------+--------------+
1 | (undefined) | Unlocked | Free | Any | 0 |
2 | (undefined) | Unlocked | Free | Any | 0 |
3 | (undefined) | Unlocked | Free | Any | 0 |
4 | (undefined) | Unlocked | Free | Any | 0 |
5 | (undefined) | Unlocked | Free | Any | 0 |
6 | (undefined) | Unlocked | Free | Any | 0 |
7 | Internal_Modem | Unlocked | Free | Modem | 0 |
-----+------------------+----------------+--------+---------+--------------+
PLUG | NAME | BOOT/SEQ DELAY | STATUS | DEFAULT |
-----+------------------+----------------+--------+---------+
1 | (undefined) | 0.5 Secs | ON | ON |
2 | (undefined) | 0.5 Secs | ON | ON |
3 | (undefined) | 0.5 Secs | ON | ON |
4 | (undefined) | 0.5 Secs | ON | ON |
-----+------------------+----------------+--------+---------+
“/H” for help.
CMS>
Figure 5.2: Main Status Screen - Text Interface
