49
lists and describes the Switch Properties fields in this window.
Base Version
Supported base management datagram (MAD) version.
Indicates that this channel adapter, switch, or router supports
versions up to and including this version. Refer to section
13.4.2, Management Datagram Format, in “InfiniBand®
Architecture, Vol. 1, Release 1.0”, for more information.
Class Version
Supported MAD class format version. Indicates that this
channel adapter, switch, or router supports versions up to, and
including, this version.
Type
Type of node being managed. The value is channel adapter,
switch, router, or error. An error entry indicates an unknown
type.
Num Ports
Number of physical ports on this node.
Port GUID
GUID of this port. A port within a node can return the node
GUID as its PortGUID if the port is an integral part of the
node and is not field-replaceable (in other words, not
swappable).
Partition Cap
Capacity of entries in the partition table for channel adapter,
router, and the switch management port. The value is the same
for all ports on the node. This is set to at least 1 for all nodes
including switches. This value is fixed and unconfigurable.
Device ID
Manufacturer-assigned device identification.
Revision
Manufacturer-assigned device revision.
Local Port Num
The link port number from which this subnet management
packet (SMP) arrived. The value is the same for all ports on
the node.
Vendor ID
Device vendor ID. The value is the same for all ports on the
node.
Description
Description of the node.
System Image GUID
GUID of the image that runs on the device.
Table 5-7: Switch Properties Window Fields
Field
Description
Linear FDB Cap
Maximum number of entries allowed in the linear unicast
forwarding table. Zero (0) indicates that there is no linear
forwarding database.
Random FDB Cap
Maximum number of entries allowed in the random unicast
forwarding table. Zero (0) indicates that there is no random
forwarding database.
MCast FDB Cap
Maximum number of entries allowed in the multicast
forwarding table.
Table 5-6: Topology Node Properties Window Fields (Continued)
Field
Description
