Table 3-6

lists and describes the elements in the Port Properties window of an Ethernet port.

Table 3-7

lists and describes the fields in the Port Properties window of an FC port.

Table 3-6: Ethernet Port Properties Window Elements

Element

Description

Port field

Displays the port number in slot#/port# notation.

Name field

Provides a port name that you can edit and apply to the port.

Type field

Displays the type of the port.

Admin Status field

Provides the up and down radio buttons so you can
configure the administrative status of the port.

Oper Status field

Indicates whether or not the port is ready for use.

Auto Negotiation Supported field

Displays true if the port supports auto-negotiation

Auto Negotiation field

Provides the Enable checkbox so you can enable or disable
auto-negotiation on the port.

Set Port Speed field

Provides radio buttons to let you configure the speed of the
port.

Current Speed field

Displays the speed of the port.

Set Port Duplex field

Provides radio buttons to let you configure the duplex
setting of the port.

Current Duplex field

Indicates whether the port runs in full duplex or half duplex
mode.

MTU field

Displays the MTU of the port, in bytes.

MAC Address field

Displays the media access control (MAC) address of the
port.

Last Changed On field

Displays the time and date of the last time that a user
configured the port.

Action field

Lets you flush the Address Resolution Protocol (ARP)
table.

Result field

Displays the result of the action that you perform from the
Action field.

Apply button

Applies the changes that you make in the Port Properties
window to the port.

Reset button

Resets the fields in the window to match the properties of
the card.

Close button

Closes the window. If you close the window before you
apply changes, CM makes no changes to the card.

Help button

Opens on-line help.

Table 3-7: Fibre Channel Port Properties Window Elements
