Agent Desktop / Laptop – New or Replacement Installation Instructions Version 2/12/2009
Agent Desktop / Laptop Installation Instructions
FOR INTERNAL STATE FARM USE ONLY
Contains CONFIDENTIAL information which may not be used without express written authorization.
- 10 -
New System
1. Unbox the new DC7100 / DC7600/DC7700 or DC7800 workstation.
a. Open the box and remove the keyboard, mouse, power cord, and computer.
b. Place the computer on the desk at this workspace.
NOTE: The DC7100 / DC7600 / DC7700 /DC7800 have fans in the front of the system for cooling.
Do NOT cover the front ventilation holes.
c. Place the user’s guide beside the workstation where the user will be able to locate it. Discard any other
materials or CDs that may be shipped with the system.
d. Remove the bar code from the outside of the shipping box. Affix the bar code to the top part of the front
of the workstation.
2. Connect the monitor using the video port.
NOTE: The HP Compaq DC7700 uses a DVI / VGA adapter, which must be installed so the monitor connects
to the expansion card and not the onboard video.
3. Connect the keyboard, mouse, and headphones to the proper ports on the back of the system. These ports are
color-coded. The mouse connects to one of the USB ports.
4. Connect the network cable to the onboard Ethernet port.
5. In the back room where the wiring cabinet is located, connect the network connection for this computer to the
Ethernet switch (any port from 9-23 on the old switch or ports 7-16 on the new router/switch combination).
** Prior to powering on, make sure all other peripheral devices are disconnected. **
T HIS PART OF THE S ECTION IS COMPLETE
NC6910 Hardware Components Setup (New and Replacement)
** Prior to powering on, make sure all peripheral devices are disconnected. **
NC6910 Hardware Components
Docking Station:
• Power
Cable
• Keyboard,
Mouse
• Kensington Cable / Keys
When Applicable:
• Monitor
• PDA
• Printer Cable
Laptop:
• CD / DVD Rom Drive (Right side of unit)
• When Applicable (Agent does not have a docking station)
• Monitor
• Power
Cable
• Mouse
• PDA
• Printer Cable
