HP t5520 - Manual (Page 49)

Administrator’s Guide www.hp.com 4-15
Control Panel
JETCET PRINT 4.0
The JETCET PRINT Professional dialog box allows you to set up the
terminal for local printing from Txtpad and Internet Explorer.
✎
Windows CE is best suited for printing small documents.
✎
Printer port designations are as follows:
- LPT1 = parallel
- LPT2 = USB
To set up a printer:
1. In the Default Printer box, select a default printer.
2. In the Manufacturer Model box, select the printer model.
3. If printing using a serial connection, in the Serial Handshaking
box select either Hardware or Software for serial handshaking
between the terminal and printer.
4. Set the appropriate print spooler options. You must select Use
Spooler for other options to become available.
5. Click the Properties button to configure printer settings. Define
printer settings as appropriate.
