ACTIVE FPL (Flight Plan)Page

FR:

Current FROM waypoint.
May also display DIRECT,
PSEUDO VORTAC, DME
ARC,

or PROCEDURE

TURN. (Figure 2-13)

TO:

Current

waypoint.

(Figure 2-13)

Waypoint Identifiers:Up to

100 waypoint identifiers may be placed on the Active Flight Plan
Pages. An identifier may be used more than once on the same Flight
Plan.

• Indented Waypoints: indicate a SID, STAR, or APPROACH

Procedure is part of the Flight Plan. (Figure 2-13, DFW)

• HP (Holding Pattern): indi-

cates a holding pattern is
programmed at a particular
waypoint. (Figure 2-14)

• PT (Procedure Turn): indi-

cates a procedure turn is
programmed at a particular
waypoint.

------: A "fence" separating the
current FR/TO leg from the
originally selected Active Flight
Plan when the TO waypoint is not on the original Flight Plan. Also sepa-
rates non-continuous Flight Plan segments. (Figure 2-13) No Auto Leg
change will occur to waypoints that appear after the fence. This type of
fence will not cause waypoints of the active flight plan to be deleted
prior to the fence if a waypoint beyond the fence is selected using the

function.

NOTE: When a "fence" (++++++) appears in an Approach it separates
the missed approach holding fix from the rest of the approach. (Figure 2-
14) No Auto Leg change will occur to waypoints beyond the fence.

******:

Same as stored Flight Plan Page.

Page Display Definitions

2-10

GNS-X

Flight Management System

Rev. 1

Jul/98

ACTIVE FPL

1/2

FR MEM

TO BWG

205 11

------

KDAL

-CMK

DFW

KHART

DEPART

ARRIVE

DIS

APPROACH

ERASE

Figure 2-13

ACTIVE FPL

2/2

RYMES -10

3000

ISLET

2000G

MAP

RW34

435G

++++++

CMK

******

DEPART

ARRIVE

ALT

APPROACH

ERASE

Figure 2-14
