If Waypoint Page Appears:
a. Waypoint Page Co-
ordinates - VERIFY
Database Waypoint
or INSERT Waypoint
Data. (Figure 3-174)
To Insert Waypoint
Coordinates (cursor over
POS Field):
(1) Latitude - IN-
SERT (N or S
first, then de-
grees, minutes,
and hundredths).
(2) ENT Key - DEPRESS.
(3) Longitude - IN-SERT (E or W first, then de-grees, min-
utes, tenths and hundredths).
b. ENT Key - DEPRESS.
8. DIS, DTK - CHECK.
NOTE: The Pilot Entered Leg Change procedure inserts a “fence”
indicated by (----) on the
DIRECT TO and ACTIVE
FPL pages preventing Auto
Leg Change beyond the TO
waypoint, if the TO waypoint
was not on the original
Active Flight Plan (Figure 3-
175) The MSG light illumi-
nates and the SYSTEM
MESSAGE Page displays
NO AUTO LEG CHG, how-
ever the AUTO field on
NAVIGATION Page 1 con-
tinues to display AUTO.
To jump the fence and continue with the flight plan use the d Key
then the Line Select Keys to position the cursor over a way point
beyond the fence then press ENT Key
WAYPOINT CORLA
POS N 33 38.30
W116 16.70
NDB-ENTER
DATABASE WPT 1/1
Figure 3-174
<
<
<
<
FR HEMET 7
TO CORLA 00:20 8
------
KSNA -KDTW
MUSEL
HEMET
DEPART
ARRIVE ETA
APPROACH ERASE
>
>
ACTIVE FPL 1/2
>
Figure 3-175
