AFIS FLT PLAN PAGE 2

WEIGHTS, FLIGHT LEVEL
AND ROUTE

RAMP WT:

Planned ramp

weight in lbs prior to starting
engines as transferred from disk
or received via the data link.
(Figure 7-10)

GROSS WT: Sum of basic
operating weight, payload, and
fuel remaining as calculated by
GNS-X

. (Figure 7-11)

NOTE: RAMP WT changes to
GROSS WT if there is an auto-
matic FUEL FLOW input, FUEL
REMAINING quantity, and
input for basic operating weight
and PAYLOAD input.

FPL LDWT: Flight planned
landing weight of aircraft at des-
tination as transferred from disk
or received via the data link.

FLT LVL:

Planned flight

level(s) as transferred from disk or received via the data link.

ROUTE: Planned route of flight as computed by Global Data Center
and transferred from disk or received via the data link.

NOTE: Pressing the AFIS or NXT Key displays the remainder of the
route (up to 50 waypoints).

UPDATE: Waypoint identifier defining position of aircraft at time of
last update request.

7-9

GNS-X

Flight Management System AFIS Operation

Rev. 0
Oct/96

RAMP WT
