System Operation
3-27 GNS-X L Flight Management System
Rev. 0
Oct/96
3. ENT Key - DEPRESS.
(Figure 3-42)
4. Line Select Key -
DEPRESS to move the
cursor to shorten or
lengthen the previously
selected segment of the
airway. If applicable,
use PRV and NXT Keys
to access all airway way-
point pages.
5. ENT Key - DEPRESS to merge the edited airway segment into
the Flight Plan and return to the Flight Plan Page.
ENTERING A STAR OR PROFILE DESCENT ON ANY STORED FPL
OR THE ACTIVE FPL PAGE
1. Line Select Key -
DEPRESS to position
cursor over ARRIVE?
field on the Flight Plan
page (Figure 3-43).
2. ENT Key - DEPRESS to
display ARRIVAL Page
(Figure 3-44).
3. ARRIVAL Airport
Identifier - VERIFY or
INSERT valid identifier.
NOTE: If the last waypoint
on the Flight Plan is an air-
port and an Approach is pro-
grammed, the ARRIVAL air-
port identifier prefills and the
cursor is over the first
TRANSITION waypoint on
the list.
If the last waypoint on the
Flight Plan is a runway, the
RUNWAY field also prefills
and the cursor is over the
first TRANSITION waypoint on the list.
FR HQM
OED
NIECE
PYE
BSR
ZONAL
TO RZS ?
AIRWAY J501 3/3
<
<
<
< >
Figure 3-42
KSEA - KLAX
KLAX
******
DEPART
ARRIVE? ETA
APPROACH ERASE
ACTIVE FPL 1/1
>
<
<
<
<
Figure 3-43
RUNWAY -----
TRANSITION -----
STAR -----
CIVET? EHF
HEL LHS
PGS PMD
TNP PTV
FIM FICKY
JLI GOATZ
ARRIVAL KLAX 1/1
> <
<
<
<
<
>
>
>
>
Figure 3-44
