Mounting and Wiring
Remote Access
Release F
UMC800 Controller Installation and User Guide
47
4/01
Step
Action
9
Set the modem switches to the following:
Switch
Setting
Position
Function
1
ON
DOWN
Modem ignores DTR (Override)
2
OFF
UP
Verbal (word) results
3
OFF
UP
Suppresses result codes
4
ON
DOWN
Suppresses echo
5
OFF
UP
Modem answers on first ring
6
ON
DOWN
CD always ON (Override)
7
OFF
UP
Loads Y0-Y4 configuration from user-defined
nonvolatile memory (NVRAM)
8
OFF
UP
Disables command recognition (dumb mode)
10
Connect the modem to the RS232 port of the UMC800 using a DB-25 male to DB-9 male
RS232 cable. Null modem cable may not work.
11
Connect the modem to a telephone jack.
12
Power up the modem and the UMC800.
13
On a remote computer, run Control Builder software.
14
Setup Control Builder to dial the UMC800.
15
Verify that communications is established with the remote UMC800.
