Mounting and Wiring
Wiring Communication Links
Release F
UMC800 Controller Installation and User Guide
41
4/01
Connector location at the rear of the operator interface
Connector Terminal Wiring
Signal
Wire
Terminal
Name
Color
Number
RX-
Black
1
RX+
White
2
RX Shd.
Shield -----
3
TX Shd.
Shield ---
TX-
Black
4
TX+
Red
5
Sig. Gnd
Black ------
6
Sig. Gnd
Green ---
Outer Shd.
Shield
7
Not Used
Not Used
8
+24 VDC
Black
9
+24VDC
Blue
10
551 Operator Interface
Rear
Connector
for Cable
from Controller
552 Operator Interface
Rear
Connector
for Cable
from Controller
+24VDC
+24VDC
Not Used
Outer Shield
24V Shield
Sig. Gnd. Shield
Sig. Gnd
Sig. Gnd
TX+
TX-
TX Shd.
RX Shd.
RX+
RX-
Blue
Black
Not Used
Shield
Shield
Shield
Green
Black
Red
Black
Shield
Shield
White
Black
Connector Terminal Wiring
Signal
Name
Wire
Color
Terminal
Number
10
9
8
7
6
5
4
3
2
1
1041 Operator Interface
Rear
Connector
for Cable
from Controller
Connec
tor Te
rminal Wiring
Signal
Wire
Terminal
Name
Color
Numbe
r
RX-
Black
1
RX+
White
2
RX Shd.
Shield ----- 3
TX Shd.
Shield ---
TX-
Black
4
TX+
Red
5
Sig. Gnd
Black ------ 6
Sig. Gnd
Green ---
Outer Shd. Shield
7
Not Used Not Used 8
+24 VDC
Black
9
+24VDC
Blue
10
Connector
for Keyboard
Figure 25 Terminal connections
