Mounting and Wiring
Plug-in Module Locations
Release F UMC800 Controller Installation and User Guide 21
4/01
Controller model number
The controller model number specified on your purchase order indicates the I/O module types and the
assigned slot location of each I/O module present in the controller.
The number fields that identify I/O
modules are defined below.
Example of controller model number
Controller Model Number 8001 - 000 - 0E - 01122300 - 56800000
I/O module types and controller
locations for . . .
Slots 1 to 8 Slots 9 to 16
So the number 01122300 - 56800000 indicates that the controller is equipped with I/O module types in the
following slot locations:
Controller
Slot #
I/O Module Type
(Module ID)
Controller
Slot #
I/O Module Type
(Module ID)
1 Blank (0) 9 DI AC Input (5)
2 Analog Input (1) 10 DO Relay Output (6)
3 Analog Input (1) 11 DO AC Output (8)
4 Analog Output (2) 12 Blank (0)
5 Analog Output (2) 13 Blank (0)
6 DI Logic Input (3) 14 Blank (0)
7 Blank (0) 15 Blank (0)
8 Blank (0) 16 Blank (0)
NOTE: The numbers (in parenthesis) that identify the I/O module types are defined in Table 6.
