Contents 51
Figure 34 The top of the processor
CAUTION: Never touch the bottom of the processor; any contaminant could prevent the mounting
pads from making contact with the socket.
CAUTION: Applying too much grease creates a gap between the contact surfaces, significantly
reducing the ability of the heat sink to draw out heat. Installing the heat sink with excessive grease
can also cause the grease to spread over the processor pins or the system board base, which can
cause electrical shorts that damage the system.
To install the new processor:
1. Insert the processor into the socket, using the key on the processor.
CAUTION: With the load lever and the retention plate disengaged, hold the processor by its edges
and align it over the empty processor socket. Make sure that you properly align the processor with
the orientation notch on the socket.
2. Engage the retention plate.
3. Engage the load lever.
